sales@bitsfrombytes.com +44 (0)1275 873792 Document No D100246

BFB 3000 Operations manual

Calibrate the Z height

A nozzle that is too high above the print bed will create a raft with a

curly look and will be very easy to remove from the print bed, The

picture on the right shows the raft rinted by a nozzle that is too high

with the bed on an angle, the raft goes from a narrow filament to a

curly filament by the end of the raft.

ADJUST THE Z HEIGHT TO CORRECT IN SMALL STEPS AS

SHOWN IN (Fig.1)

Re-print the test raft file to check the new z height

nozzles that are too high

Z height adjuster

Z Adjuster

locking nut

Turn the Z height

adjuster anti-

clockwise as

shown

To decrease the

gap between the

bed and nozzle.

Fig.1
