sales@bitsfrombytes.com +44 (0)1275 873792 Document No D100246

BFB 3000 Operations manual

step

• Offer the base panel to the bottom of the main unit making sure you have the single filament reel holders is at the

back of the machine near the Z lead screw.

• Secure the base panel by screwing the 4 feet through the holes in the base panel and into the bottom corner blocks

Base panel

Two filament reel

holders at the top

Tighten firmly to

give the machine a

solid platform

Screw the feet into

the bottom corner

block

Unpacking and assembling BFB 3000
