White State reflectivity: 30% (typical)

Contrast Ratio: 8:1 (typical)

Viewing Angle: > 70 degree

Switching speed: 500 ms

Colors: Black & White

Operating System Linux OS

Storage 64M*8 NAND Flash (Samsung),

8MB NOR Flash (SPANSON, S29JL)

Memory SDRAM: 1M*32*4 bank 143MHz

SRAM: 256K * 16

Internal 4MB NOR FLASH

Audio Philips Audio codec SOT28 (Audio JACK-

2.6mm)

USB USB 1.1 (Mini-connector 5P)

SD-Slot SD Card 1.0 (Connector Push-Push)

Operating Temperature Range: 0~50C

Storage Temperature Range: -25~70C

Supply Voltage 3.0V

UART 3-channel, Supports 5-bit, 6-bit, 7-bit, or 8-bit

serial data transmit/receive (Tx/Rx)

Table 7.1: Hardware Specifications [49], [51]

Figure 7.1: The EBR-Development kit Block Diagram, (courtesy of PVI)

7.2 Configuration

Linux 2.4.18 OS is ported on the Samsung S3C2410-ARM9 CPU, which creates the

flexibility of writing the source codes in C-language using a low level Graphic User Interface-

API called Nano-X. To achieve this all source codes transferred to the hardware was cross-

compiled with an arm-linux-gcc tool-chain.
